Stand Robust, vibration-free stand on a cross base with four lockable caster wheels
Binocular Tubes 0-210° tiltable head configured with Rotoplate, DBSi (inclined double beam
splitter), Double iris and DSLR Adapter
IPD Adjustment 50-75 mm
Eyepieces WF 10X/18 mm lockable eyepieces, one with resolution markup to assist in
diopter adjustment
Diopter Adjustment ± 5mm with diopter lock
Apochromatic Magnichanger Galilean Zoom 1:6, convertible to 8 step magnichanger
Zoom Range 0.4-2.5X
Objective NuVar system with variable focal length adjustment from 300-400 mm
with fine focus mechanism
Light Source 50 watt LED, 90-240V
Maximum Wattage 195 watts
Built-in Filters Yellow and Green
Vertical Movement of Arm ± 250 mm, power saving feature with light cut-off in park position
Microscope Carrier ABA (Automatic Balancing Arm) with electromagnetic release for easy, driftfree
positioning
Mounting Options Floor stand, wall mount and ceiling mount
